Glasliner Ceiling Tiles are lightweight and cut-to-size for fast installation and easy maintenance. They will not harbor mold, mildew and bacteria. A special resin formulation results in a strong rigid ceiling panel with minimal deflection. Glasliner ceiling panels can help improve indoor air quality, and inhibits the growth of bacteria, fungi, and other microorganisms.

	Physical Specifications
0.100 in Nominal Thickness / 1300 Series
Property	Value	Test Method
Flexural Strength	8,000 psi	ASTM D790
Flexural Modulus	6.0 x 10⁵ psi	ASTM D790
Tensile Strength	8,000 psi	ASTM D638
Tensile Modulus	9.43 x 10⁵ psi	ASTM D638
% Elongation	1.20 %	ASTM D638
Izod Impact	7.0 ft-lb/in	ASTM D256
Coefﬁcient of Linear Thermal Expansion	2.22 x 10^-5 in/in/°F	ASTM D696
Barcol Hardness	40	ASTM D2583
Sag tolerance	≤ 0.25 in	N/A
Abrasion Resistance	0.293 % Wt. Loss	Taber Test
Water Absorption	0.17% – 72 hr @ 77°F	ASTM D570
Specific Gravity	1.6138	ASTM D792
Flame Spread	≤ 200	ASTM E84
Smoke Development Index	< 450	ASTM E84

Standard Specifications

Glasliner FRP Ceiling Panels conform to the specification set on ASTM D5319:
Flammability Classification: Class C – Flame spread index 76 to 200, smoke development index of 450 or less.
Thickness classification: Grade 6 – 0.081 to 0.099 in. (2.06 to 2.51 mm); 0.090 in. nominal (2.29 mm) (data valid only for 1300 series panels).
Size (Length and Width): Specified length and width ±1/8 in.
Squareness: ±1/8 in.
Thickness: Specified thickness ±10 %.
Color: Panel color shall be per specification. Within 1 DE of the specified color using the CIELab scale.
Panels shall have a pebble texture front side. Panel backside is smooth and may possess slight imperfections that do not adversely affect performance or physical properties and are not cause for rejection.
Panels shall be installed in strict accordance with Glasliner FRP panel Installation Instructions (D-SA-01).

Approvals & Certifications

Manufactured on an ISO 9001 Certified plant (TÜV Rhineland of North America, lnc.; Certificate Registration No. 74 300 3629)
Certified Product under Greenguard and Greenguard Gold criteria (Certificates Number: 23966-410 and 23966-420)
Meets USDA/FSIS requirements
Canadian Food Inspection Agency and Agriculture Canada approved
Meets minimum requirements of major model building codes for Class C interior wall and ceiling ﬁnishes of ﬂame spread ≤ 200, smoke developed index 450 or less (per ASTM E84)
Mold & Mildew Resistant per ASTM D3273 and D3274 tests
