Scuff Panels | Stabilit America

Description

Technical Data

Stabilit transportation scuff liner is a high strength fiberglass composite panel. It is tough, durable and USDA approved. Panels provide great impact and abrasion resistance, and are extremely resistant to moisture. Wall liner panels also protect against a wide range of chemicals and are rustproof and mildew resistant.

	Physical Characteristics
Thickness	Color	Width	Finish	Weight
.120	White	12″, 16″, 24″, 48″	Embossed	.81 lbs. Sq. Ft.

	Technical Characteristics
Property	Typical Value	Test Method
Flexural Strength	22,703 PSI	ASTM D-790
Flexural Modulus	880,000 PSI	ASTM D-790
Tensile Strength	12,329 PSI	ASTM D-638
Tensile Modulus	950,000 PSI	ASTM D-638
Izod Impact (Notched)	8.51 Ft. Lbs.	ASTM D-256
Barcol Hardness	45	ASTM D-2583

Downloads

Steeliner Sheet

Format: pdf

Download

Steeliner Warranty

Format: pdf

Download

Scuff liner .120 TD

Format: pdf

Download

MSDS 2017

Format: pdf

Download

Typical Applications

Designed for use as scuff liner in trailers and truck bodies.
